Specification

Benefits in practice:

• Dual sensor for measuring the thickness of non-magnetic layers on each magnetic and non - magnetic metals
• Wide measuring range from 0 to 2,000 µm
• Error indicator incorrect measurement
• Simple zero -point calibration for rapid deployment and high precision
• Memory for up to 2,500 measurements
• All memory values and groups directly stored in the unit
• Bluetooth interface for PC data transfer
• Simple one-handed operation
• The light adjustable backlight
• Automatic switch off

Technical details:

• Sensor: Ferromagnetic Substrates
• Operating principle: magnetic induction
• Guaranteed tolerance: 0 ~ 1000 µm (± 2 % ±2 µm); 1000 ~ 2000 µm (± 3.5 %)
• Bending radius minimum: (Surface) 1.5 mm
• Minimum measured surface: Ø 7 mm
• Critical base layer thickness: 0.5 μm
• Measuring range: 0 bis 2,000 μm
• Accuracy: 0 ~ 100 µm (0.1 µm); 100 ~ 1000 µm (1 µm); 1000 ~ 2000 µm (0.01 mm)


• Sensor: NE-metallic substrates
• Operating principle: eddy current
• Guaranteed tolerance: 0 ~ 1000 µm (± 2 % ±2 µm); 1000 ~ 2000 µm (± 3.5 %)
• Bending radius minimum: (Surface) 3 mm
• Minimum measured surface: Ø 5 mm
• Critical base layer thickness: 0.3 μm
• Measuring range: 0 bis 2,000 μm
• Accuracy: 0 ~ 100 µm (0.1 µm); 100 ~ 1000 µm (1 µm); 1000 ~ 2000 µm (0.01 mm)


• Functions: error indicator for measurement error, adaptive backlight, auto power off, Bluetooth
• Dimensions: 113,5 x 54 x 27 mm
• Weight: 110 g (incl. batteries)
