Model : AQMGP 11-02
Product : AQMESH (Inggris)
Fungsi : Alat ukur kualitas udara ambient secara otomatis
| Parameters : | |||
| ▪ | Dust PM10 | : | 0 - 1,000 µg/m3 |
| ▪ | Dust PM2.5 | : | 0 - 500 µg/m3 |
| ▪ | NO | : | 0 - 4.000 ppb |
| ▪ | NO2 | : | 0 - 4.000 ppb |
| ▪ | CO | : | 0 - 6000 ppm |
| ▪ | SO2 | : | 0 - 10,000 ppm |
| ▪ | Ozone (O3) | : | 0 - 1,800 ppb |
| ▪ | Temperature | : | -20 to + 100°C |
| ▪ | Relative Humidity | : | 0 - 100% RH |
| Specification : | |||
| ▪ | Sensor life | : | Up to 2 years |
| ▪ | Power Options | : | Primary lithium metal batteries #3. Up to years operation (depending on |
| measurement strategi) Main power option, External 12 DC power option, | |||
| Rechargeable NiMH Battery and Charger option | |||
| ▪ | Communication | : | Raw data sent to remote server via wireless |
| Communications-Data access contract may be required | |||
| ▪ | Physical | : | Enclosure Polyurethane moulded or ABS, Protection IP65 |
| Approx size L170xW220xH250mm (not inc antennaa 180mm) | |||
| Weight <2kg | |||
| ▪ | Mounting | : | Various mounting accessories available |
| ▪ | Meas. period | : | Variable, from 1 minute to 1 hours |
| ▪ | Server software | : | Web browser based, processing of row data to give indicate |
| concentration, database storage on secure server, data acces-tables, | |||
| graph, data downloadd, multii-user access, pasword controlled | |||
